Custom Zinc Electroplating of Die Castings for the Military Industry

New Method Plating Co., Inc. was approached to perform custom zinc plating services for a military industry customer. The precision zinc plating was to be performed on die castings to be used in an electronics application. For this reason, the work needed to be performed to extremely tight tolerances (0.0002″ – 0.0004″).

New Method Plating Co., Inc. maintains Fisher x-ray technology to be able to perform such precise thickness testing. Using customer-supplied gauges, they were able to confirm that tolerance requirements were successfully met. Additional quality testing (ASTM B633 TY II Fe/ZN 5; ISO 9001:2015 AS9100) was performed to verify adherence to the quality standards that New Method Plating Co., Inc. customers have come to expect since the company’s founding in 1931.

Final product measured O.D. Ø 1.25″ x 0.75″ high. In addition to the zinc plating, the die castings were finished with olive drab and black chromate. By employing state-of-the-art equipment (for example, an automatic station return plating line, amongst other premium equipment), New Method Plating Co., Inc. was able to turn around 10,000 die castings in just three days.

To learn more about this custom zinc plating military project or other projects or services, please contact New Method Plating Co., Inc.

Custom Zinc Electroplating of Die Castings - Project Details

Custom Zinc Plating Product Description

This product is used in an electronic application for military.

Custom Zinc Plating Capabilities Applied / Processes

Primary

Zinc Plating

Equipment Used to Electroplate Part

Automatic Station Return Plating Line

Overall Part Dimensions

O.D.: Ø 1.25"

Height: 0.75"

Tightest Tolerances

0.0002" - 0.0004"

Material Finish

Plating: .0002 Zinc

Conversion Coating: Olive Drab Chromate

Conversion Coating: Black Chromate

In Process Testing / Inspection Performed

Fisher X-Ray Technology for Precise Thickness Testing

Gages Provided by Customer

Quality Testing per ASTM B633, ISO 9001:2015 and AS9100

Industry for Use

Military Industry

Volume

10,000

Delivery / Turnaround Time

3 days

Delivery Location

Rhode Island

Standards Met

ASTM B633 TY II Fe / ZN 5

Product Name

Zinc with Olive Drab and Black Chromate
